3. Display
Telemetry
Emission Control
• Request Force Regen
• Inhibit Regen Disable/Enable
Throttle
• Minimum RPM
• Idle RPM
• Maximum RPM
• Switch/Rotary
– Switch RPM
– Increment
– Rotary RPM
– Increment
– Max RPM
– Change / sec
Autostart
• Behavior
– Operation
*
High→Low
*
Low→High
– Start-Stop With
*
Dual Switch, Single Switch, Transducer, Transducer w/ Backup Switches, Scheduler
Only, Timed Run, Cycle Run, Single Start/Stop, Remote Control, Pressure Washer
– Start Enable Delay (s)
– Stop Enable Delay (s)
– Maintain Transducer
*
Maintain Function
· Disable
· Low→High
· High→Low
*
Auto Throttle Input
· Transducer 1,2,3,4,5,6
*
Target Point
*
Throttle Aggressiveness
*
Error Operation
· Controlled Stop, Immediate Stop, Go to Run, Derate
• Ramp Profile
LOFA document No. 463-3002-59 Page 13
