User Manual
LogicS-2 / LogicS-3
Page 27/33
off)
Switching Capacity 5% (30 sec on / 9:30
min off)
360VA / 13A / 28V @ 25°C
Switching Capacity 10% (1 min on / 9 min
off)
13A upwards, 2A downwards
Weight 2,1 kg
Technial Data LogicS-2-XXX-240VA
Switching Capacity 10% (1 min on / 9 min
off)
240VA / 9A / 27V @ 25°C
Switching Capacity 5% (30 sec on / 9:30
min off)
260VA / 11A / 24V @ 25°C
Switching Capacity 10% (1 min on / 9 min
off)
11A upwards, 3A downwards
Weight 1,9 kg
Technial Data LogicS-2-XXX-140VA
Switching Capacity 10% (1 min on / 9 min
off)
140VA / 6A / 24V @ 25°C
Switching Capacity 5% (30 sec on / 9:30
min off)
160VA / 7A / 22V @ 25°C
Switching Capacity 10% (1 min on / 9 min
off)
11A upwards, 3A downwards
Weight 1,4 kg
Type Label
The following figure shows the type label and its location on the control box
housing.
Note: Specifications on the type label are dependent on the version of
the LogicS control box (see technical data).
