5. Technical Data
General
Supply Voltage
110V ± 6% / 60 Hz
Standby-Consumption primary 1,1 W
Operating Voltage Electronics
5VDC ± 5% 150mA
Hall Sensor Operating Voltage
5VDC ± 10% 150mA
Ambient Temperature 0 - 35°C
Operation Humidity 5 – 85% (non condensing)
Storage Humidity 5 – 90% (non condensing)
Protection Class (with grounding terminal) I
Protection Class (without grounding
terminal)
II
Mains Cable 3 m
Dimensions (L, B, H) [mm] 214 x 109 x 62
Technial Data LogicS-3-XXX-360VA
Switching Capacity 10% (1 min on / 9 min
off)
360VA / 11A / 33V @ 25°C
Switching Capacity 5% (30 sec on / 9:30
min off)
390VA / 13A / 30V @ 25°C
Switching Capacity 10% (1 min on / 9 min
off)
13A upwards, 2A downwards
Weight 2,6 kg
Technial Data LogicS-3-XXX-340VA
Switching Capacity 10% (1 min on / 9 min
off)
340VA / 11A / 31V @ 25°C
Switching Capacity 5% (30 sec on / 9:30
min off)
360VA / 13A / 28V @ 25°C
Switching Capacity 10% (1 min on / 9 min
off)
13A upwards, 2A downwards
Weight 2,2 kg
Technial Data LogicS-2-XXX-340VA
Switching Capacity 10% (1 min on / 9 min 340VA / 11A / 31V @ 25°C
