G120F/G160F/G200F Part IV Disassembly and maintenance
- 35 -
5) Feed the rope through the starter case hole and the
starter grip; then make a figure eight knot at the rope
end.
6) Assemble the ratchets and then tighten them with
special bolts.
Pay special attention to the installation direction of
the ratchets.
7) Check the operation of the ratchet by pulling the
starter rope out several times.
Starter case hole
