(2) Machine introduction
(3) Nozzle module exploded view
Gantry
Base
Filament Rack
Nozzle module
Extruder module
Hot bed
Teflon tube
Sheet metal
fixed block
Quick pneumatic joint
Heat sink
Heating block
Nozzle
Heater
Thermistor
Sheet metal
protective case
small fan
Big fan
Air guide
