TR700 Instruction Manual
13
09
Distribution of
external control input
2
3
0-8
1
Tare
2
Clear zero
3-7
Extend Functions
8
Keyboard lock
，
only lock the “zero, tare, gr/nt”
keys
10
Distribution of
external control input
3
3
0-8
0
Gross/net
1
Tare
2
Clear zero
3-7
Extended Functions
8
Keyboard lock
，
only lock the “zero, tare and gr/nt”
keys
11
Distribution of
external control input
4
3
0-8
0
Gross/net
1
Tare
2
Clear zero
3-7
Extended Functions
8
Keyboard lock
，
only lock the “zero, tare and gr/nt”
keys
12
Distribution of relay
output 1
1
0-8
0
Forbidden output
1
Hi-Hi limit output
2
Hi limit output
3
Lo limit output
4
Lo-Lo limit output
5-8
Extended function
13
Distribution of relay
output 2
2
0-8
0
Forbidden output
1
Hi-Hi limit output
2
Hi limit output
3
Lo limit output
4
Lo-Lo limit output
5-8
Extended function
14
Distribution of relay
output 3
3
0-8
0
Forbidden output
1
Hi-Hi limit output
2
Hi limit output
3
Lo limit output
4
Lo-Lo limit output
5-8
Extended function
15
Distribution of relay
output 4
4
0-8
0
Forbidden output
1
Hi-Hi limit output
2
Hi limit output
3
Lo limit output
4
Lo-Lo limit output
5-8
Extended function
