6.3. List of Communication Parameters of Serial Interface 1
Number
C-XX
Name
Default
Setting
Parameter
range
Description
00
Communication
address
1
0-99
Communication address
01
Baud rate
1
0
4800 bps
1
9600 bps
2
19200 bps
3
38400 bps
4
57600 bps
5
115200 bps
02
Parity bit
2
0-2
0
Non
1
Odd
2
Even
03
Data bit
0
0-1
0
7
1
8
04
Communication mode
1
0-1
0
Continuous mode
1
instruction mode
05
Communication rate
2
0-5
0
4 times per second
1
8 times per second
2
16 times per
second
3
20 times per
second
4
32 times per
second
5
50 times per
second
6
60 times per
second
06
Communication
protocol
0
0-3
0
Zhimei protocol
1
Modbus protocol
2
Longtec protocol
6.4. Communication Protocol of Serial Interface 1
6.4.1. Zhimei Protocol
6.4.1.1. Signal Format
Data bit = 7 or 8;
