TR700 Instruction Manual
24
6.4.3. Longtec Protocol
6.4.3.1. Signal Format
Data bit = 8;
Parity bit = 1（non, even or odd）;
Stop bit = 1;
Function code 10 Function code
0F
Setting address
higher (bytes)
00
Setting address
higher (bytes)
00
Setting address
lower (bytes)
05 Setting address
lower (bytes)
05
Setting data
higher (bytes)
00 Setting data
higher (bytes)
00
Setting data
lower (bytes)
0C Setting data
lower (bytes)
0C
Take count of bytes 18
Data 1 (higher byte)
00
Data 1 (lower byte)
13
Data 2 (higher byte) 00
Data 2 (lower byte) 88
Data 3 (higher byte)
00
Data 3 (lower byte) 0F
Data 4 (higher byte) 00
Data 4 (lower byte) A0
Data 5 (higher byte) 00
Data 5 (lower byte) 0B
Data 6 (higher byte) 00
Data 6 (lower byte) B8
Data 7 (higher byte) 00
Data 7 (lower byte) 07
Data 8 (higher byte)
00
Data 8 (lower byte) D0
Data 9 (higher byte) 00
Data 9 (lower byte) 10
Data 10 (higher byte) 00
Data 10 (lower byte) 11
Data 11 (higher byte) 00
Data 11 (lower byte)
12
Data 12 (higher byte) 00
Data 12 (lower byte)
13
