TR700 Instruction Manual
23
（hex）
Address domain
01
Address domain
01
Function code
06
Function code
06
Setting address higher
(bytes)
00
Setting address higher
(bytes)
00
Setting address lower
(bytes)
11
Setting address lower
(bytes)
11
Setting data higher (bytes)
00
Setting data higher
(bytes)
00
Setting data lower (bytes)
05
Setting data lower (bytes)
05
Function code： 0X10 Set Multi-holding-Register
Example: Hi-hi limit value：5000 Higher limit value：4000
Lower limit value：3000 Lo-lo limit：2000
Hi-hi Limit Lag: 16 Higher Limit Lag: 17 Lower Limit Lag: 18 Lo-lo Limit Lag: 19
The slaver’s number is 01. Set 12 registers’ values from the 6th one to the 12th one.
Request
Response
Domain name Data （hex） Domain name
Data （hex）
Address domain 01 Address domain 01
