TR700 Instruction Manual
63
11.1.3. Parameter List of Calibration in Kind
CAL1
Name
Defaul
t
Setting
Parameter range
Descriptions
C1.dEC
i
decimal point
0
0-4
0
：
No decimal place 12345
1
：
1 decimal places 1234.5
2：2 decimal places 123.45
3：3 decimal places 12.345
4：4 decimal places 1.2345
C1.d
Division
1
1、2、5、10、
20、50
The minimum weighing division can
be any one of 1、2、5、10、20、50.
C1.MA
X
Full capacity
10000
100-900000
The maximum range of weighing;
This setting value ＋ 9d
can be
displayed.
While the weight exceeds the above
value, it cannot be displayed.
C1.ZEr
o
Zero calibration
0.1mV
0.05uV-15mV
The voltage that is input from the load
cell at zero is decided in the zero
calibration. The unit is mV.
C1.SPA
n
Capacity calibration
10000
100-900000
In the calibration in kind, the voltage
input from the load cell is decided in
the capacity calibration.
It is the difference between weighing
point and zero point. The unit is mV.
