Longtec TR700 - Parameter List of Digital Calibration

TR700 Instruction Manual
64
11.1.4. Parameter List of Digital Calibration
CAL2
Name Default
Setting
Parameters’
range
Descriptions
C2.dEC
i
Position of decimal
point
0
0-4
0：No decimal place 12345
1：1 decimal places 1234.5
2
：
2 decimal places 123.45
3
：
3 decimal places 12.345
4
：
4 decimal places 1.2345
C2.d
Division
1
1、2、5、10、
20、50
The minimum weighing division can
be any one of 1、2、5、10、20、50.
C2.MA
X
Full Capacity
10000
100－900000
The maximum range of weighing;
This setting value ＋
9dcan be
displayed.
While the weight exceeds the above
value, it can not be displayed.
C2.ZEr
o
Zero calibration
0.1mV
0.05uV-15mV
The voltage that is input from the
load cell at zero is decided in the zero
calibration. The unit is mV.
C2.SEn
Input sensitivity
1mV/V
Max 5mV/V
The input sensitivity of load cells
C2.SPA
n
Capacity calibration
10000
100－900000
The maximum capacity of load cells
