 Description of Status Word of Response：
If the higher four bits and the lower four bits are not in accord, get back to 0x75. If they are in
accord, get back to the following table.
b7 = b3 B6 = b2 B5 = b1 B4 = b0
1
0
1
0
1
0
1
0
OUT4
Successfull
y modified
OUT4
Unsucce
s-sfully
modifie
d
OUT3
Successfull
y modified
OUT3
Unsucce
s-sfully
modifie
d
OUT2
Successfull
y modified
OUT2
Unsucce
s-sfully
modifie
d
OUT1
Successful
ly
modified
OUT1
Unsucce
s-sfully
modifie
d
6.4.3.3.10. Read the Function Parameters
Request
：
Master
Response
：
Slaver
Domain name Data（hex） Domain name Data（hex）
Beginning code 7E Beginning code 7E
Address 01-63 Address 01-63
Function code 20 Function code 20
Length of data 0 Length of data 4
Checking
Accumulati
on
Range of zero
tracking Range of clearing to zero
Filtering coefficient
Range of dynamic
detection
Unit setting Display updating rate
Conditions of
comparison out Sampling rate
Checking Accumulati
on
The meanings of the parameters are referred to Table 5-1.
6.4.3.3.11. Read the Parameters of DIDO Distribution
Request：Master Response：Slaver
Domain name Data（hex） Domain name Data（hex）
Beginning
code
7E Beginning code 7E
