TR700 Instruction Manual
56
Function
number
Function name
Default
Setting
The range of parameters
Descriptio
n
SEt-HH
Hi-hi limit
value
4000
0－999999
SEt-H
Higher limit
value
3000
0－999999
SEt-L
Lower limit
value
2000
0－999999
SEt-LL
Lo-lo limit
value
1000
0－999999
LAg-HH
Hi-hi limit lag
10
0
－
100
LAg-H
Higher limit lag
10
0－100
LAg-L
Lower limit lag
10
0
－
100
LAg-LL
Lo-lo limit lag
10
0－100
The condition：hi-hi limit value≥higher limit value≥lower limit value≥lo-lo limit value
Note： 1. When one of the higher/lower limit value is set “0”, it will not be compared. For
example, if HH is set “00”, “HH” will not be compared, i.e. the output terminal of “HH” is invalid.
2．Lag：the range of the delay after alarm, the unit is “d”.
Example：HH limit value is 1000，and the lag is 20.
When the value participating in the comparison ≥1000, the alarm starts. The comparison
is selected by the comparison
condition of F7.
When the value participating in the comparison≤1000-20, the alarm exits. The comparison
is selected by the comparison
condition of F7.
In the upper/lower setting, the former two bits before“-”display the limit value，the
latter three bits display the lag.
Note：The range of lag is 000-100。The lag>100，”Err” is displayed for about 2 seconds
and get back to “SET-HH” automatically。
