LOOP EV-Flex EVSE - Page 21

6. Insert the SIM card.
Figure 3-24 Insert the SIM card
7. Close the SIM card socket and push the cover toward lock direction to lock the cover.
Figure 3-25 Lock SIM card socket cover
8. Reassemble the top cover. Please refer to the following torque. SIM card installation is completed.
Screw Torque
M6 16 kgf.cm 13.88 lb-in
21
Loop EV-Flex
TM
EVSE
EVS-32A-L2-001 (R-Model)
v.20.9.4
www.evLoop.io
