LOOP EV-Flex EVSE - Introduction; Product Overview and Box Contents

1. Introduction
This user manual applies to “32A Level 2 AC Charger for Plug-in Electric Vehicles (PEVs) and Battery Electric Vehicles
(BEVs)”.
!!! Any unauthorized modifications will void the manufacturer’s warranty !!!
1.1. Product Overview
Description Quantity Remark
1 Loop EV-Flex EVSE
+ SAE J1772 Connector
+ OLED Display
+ RFID Icon
2 Mounting Bracket 1 Attached to the back of the Loop EV-Flex EVSE
3 Holster 1 With Hook x1, Holster x1 & M4xL15 tapping screw x2
4 Screw Bag 1 With #12xL50 tapping screw x4
Figure 1-1 - Box Contents
Table 1-1 - Accessories in the box
7
Loop EV-Flex
TM
EVSE
EVS-32A-L2-001 (R-Model)
v.20.9.4
