LOOP EV-Flex EVSE - Install the SIM Card

3.5. Install the SIM card (Optional)
1. Disassemble top cover & Loosen the star screws (x5)
Figure 3-19 Five screws in the Base Cover position
2. Find SIM card socket
Figure 3-20 Position of SIM card socket
19
Loop EV-Flex
TM
EVSE
EVS-32A-L2-001 (R-Model)
v.20.9.4
www.evLoop.io
