3. Installation & Conguration
3.1. Before Installation
3.1.A. Safety Check
CAUTION: Disconnect the power supply before installing or repairing the Loop EV-Flex EVSE. Failure to
do so may result in physical injury or damage to the power supply system and the Loop EV-Flex EVSE.
The Loop EV-Flex EVSE must be installed only by a licensed electrician in accordance with the provisions of the local
electrical industry construction and should comply with national electrical codes and standards.
Before installing the Loop EV-Flex EVSE, make sure you have read all instructions in this manual and fully understand
its contents.
Proper protective equipment is required when connecting to a main switchboard. The tools and parts used as outlined
in the section “Tools & parts required for installation”.
3.1.B. Grounding Instructions
The Loop EV-Flex EVSE must be equipment grounded through an equipment grounding conductor. Use a wire with a
dedicated grounding wire and a ring terminal and connected to the equipment ground terminal block for grounding.
3.2. Tools and Parts Required for Installation
Tool Quantity Size Supplier Remark
Mounting Bracket 1 194x109x9 mm Model Accessories
Fasten Loop EV-Flex
EVSE to the wall
Holster Assembly 1 58x58x70 mm Model Accessories
Hold EV charging
connector & cord
Screw 4
Tapping: #12 Model Accessories
Fasten Mounting
Bracket & Hook
Mechanical: M6 Commercially Available
Wire, Copper 3 8 AWG Commercially Available UL1015 (recommended)
Heat Shrink Tube 3 For 8 AWG wire Commercially Available
Protect wires &
terminals
Terminal 3 For 8 AWG wire Commercially Available
Connect input wires to
the terminal block
Conduit 1 1 inch Commercially Available Protect power cable
Torx Screwdriver 1 T20 Commercially Available
Philips Screwdriver 1 PH3 Commercially Available
Hexagon Socket 1 5/16 Commercially Available
Tighten #12 Tapping
screws
Torque Wrench 1 35 kgf-cm min Commercially Available
Table 3-1 Tools & parts required for installation
