Warning Settings
Temperature Low: Value in Celsius at which the Loop EV-Flex EVSE will send a temperature low warning message.
Temperature High: Value in Celsius at which the Loop EV-Flex EVSE will send a temperature high warning message.
Voltage Low: Value at which the Loop EV-Flex EVSE will send an under-voltage warning message.
Voltage High: Value at which the Loop EV-Flex EVSE will send an over voltage warning message.
General Settings
Output Power Type: AC or DC output power.
Power Phase Connected: Input power phase connected to the Loop EV-Flex EVSE to indicate single phase or three
phases. This value is always “1”.
Max Amperage HW Setting: The DIP switches (Hardware) settings to indicate the maximum charging current.
Max Amperage FW Setting: The software settings to indicate the maximum charging current.
PWM Amperage: The PWM setting for charging current when the Loop EV-Flex EVSE is online. This signal is to tell EV
how much current is allowed to use.
Real Amperage: The real-time charging current detected by the Loop EV-Flex EVSE.
Cold Load Pickup Max Delay: Default cold load pickup delay is 120s ~ 720s. The max value could be changeable by
this property.
Plug and Charge ID: If the value is present, the Loop EV-Flex EVSE needs to support plug and charge scenario by us-
ing the specic identier. If absent, authorization for each session is required. This ID must be 8 or more characters.
Reservation Supported: If true, the Loop EV-Flex EVSE will support reservation related messages from Central Sys-
tem.
Resume Charge After Reboot: Indicate if the Loop EV-Flex EVSE resumes charging after power recycle. If true, the
Loop EV-Flex EVSE will resume charging according to UL regulations. If false, the Loop EV-Flex EVSE will not resume
charging.
RFID Reader: Indicate if RFID reader is available.
Ventilation Required: Indicate if ventilation equipment is required. If set this option to yes, a ventilation fault will oc-
cur when the EV report for need ventilation equipment. Recommend setup value are shown below according to the
place and ventilation equipment available or not.
Place Ventilation Equipment Available Ventilation Equipment NOT Available
Indoor No Yes
Outdoor No No
Skip HeartBeat Message: Indicate if HeartBeat message is skipped if any other message is sent successfully during
a heartbeat interval.
