right
a
CAUTION – When you t the pipe into
the pump hold the pump only at the top
chamber!
Figure 26: How to hold the pump end
Lower the pump end carefully onto the motor and
x it with the supplied screws. It is very important to
avoid heavy impact when the pump end is mounted
onto the motor.
wrong
Figure 27: Connection pump end with motor 8.2.7 Installation
To connect the pump end and the motor you have
to set the motor with the clamps in the borehole
to x it, see also gure below, "Figure 23: Motor in
borehole".
Make sure that the clamps rest on a sucient stable
support structure, for example the well casing. If the
structure is not strong enough to carry the weight a
support structure has to be built that is suitable for
the installation process.
Screw the rst piece of the pipe into the pump and
install a second clamp at the pipe, see also gure
below "Figure 24: Preassembly of the pump" on page
58.
a
CAUTION – Make sure that the motor
cable is outside the clamps, otherwise
you will damage the cable.
a
NOTE - Do connect the clamp directly
under the ange to leave some space for
mounting the bolts.
If threaded joints are used instead of anges they
must t together to ensure that they do not work
loose when subjected to the torque reaction caused
by the starting and stopping of the pump.
Figure 23: Motor in borehole
Figure 25: Installation depth of the rst piece of pipe
The thread on the rst section of the riser pipe
which is to be screwed into the pump should not be
longer than the threads in the pipe, see also „Figure
25: Installation depth of the rst piece of pipe“ on
page 58.
Figure 24: Preassembly of the pump
wrong
Right
Wrong
