LH050 Series System
Specifications
24
System
Operating System Linux (embedded)
Pentaplex Simultaneous view, record, playback, backup & re-
mote monitoring
Number of Channels
4 channels
Inputs/Ouputs
Video IN None (wireless)
Video OUT 1 x HDMI, 1 x VGA
VGA OUT
Yes
HDMI Yes
Audio IN None
Audio OUT None
USB Port 2x USB (one at front and one at back panel)
Alarm IN Alarm IN not supported
Alarm OUT Alarm OUT not supported
Video Output Resolution 1920x1080 (HDMI), 1440x900, 1280x1024,
1280x720, 1024x768
PTZ Control
PTZ cameras not supported
Display
Live Display 1, 4
Live Display Speed 120 NTSC, 100 PAL
System Navigation USB mouse, IR remote controller
Motion Area Setting None
Sensitivity Levels
3
Firmware Upgrade
Automatic over the Internet & via USB device and
network
User Authority By user group
Time Synchronization
Auto time sync by NTP server
Recording
Video Compression H.264
Audio Compression None
Recording Resolution NTSC: 1280x720 (720p)
PAL: 1280x720 (720p)
Recording Quality Control
3 levels
Recording Schedule By hour, by day, by recording mode, by motion, by
channel
Pre Recording
Max. 10 Secs
Post Recording Max. 5 Minutes
Reliability Watch-Dog, auto-recovery after power failure
Covert Video
No
#LX400066; r. 1.0/26388/26388; en-US
137
