Basic Setup (LH050 Series)
6
6.1 Step 1: Connect the DVR Docking Stand (OPTIONAL)
The DVR can be positioned in an upright, vertical
position using the included docking stand, or laid
horizontally.
• For vertical orientation, position the DVR over
the docking stand. Push down on the DVR until
you hear a “click”.
• To remove the DVR from the docking stand,
hold the docking stand down firmly on a flat sur-
face and pull the DVR up.
6.2 Step 2: Connect Wireless Cameras to the DVR
1. Connect the wireless camera cable to the included power adapter, then connect to a
local power outlet or surge protector.
2. Connect the wireless receiver to the rear USB port.
#LX400066; r. 1.0/26388/26388; en-US
