LS Industrial Systems XBC-DR10E User Manual

Chapter 6 Instruction and Flag List
XBC E-Type Main Unit 6-2 Ver. 1
6.2 Basic Instructions
6.2.1 Contact Point Instruction
Classification Designations Name
Details
Page
Contact
Point
LOAD
Normally Open Contact
6-37
LOAD NOT Normally Closed Contact
AND AND Normally Open Contact
6-39
AND NOT
AND Normally Closed Contact
OR OR Normally Open Contact
6-40
OR NOT OR Normally Closed Contact
LOADP Normally Open Contact Rising Edge
6-37
LOADN Normally Open Contact Falling Edge
ANDP AND Normally Open Contact Rising Edge
6-39
ANDN AND Normally Open Contact Falling Edge
ORP OR Normally Open Contact Rising Edge
6-40
ORN OR Normally Open Contact Falling Edge
6.2.2 Union Instruction
Classification Designations Name
Details
Page
Unite
AND LOAD
Mnemonic AND Normally Open Contact
6-43
OR LOAD
Mnemonic OR Normally Open Contact
6-45
MPUSH
Mnemonic Operations up to Present
6-47
MLOAD
Mnemonic Previous Operation Result
MPOP
Mnemonic Delete Previous Operation Result
6.2.3 Reverse Instruction
Classification Designations Name
Details
Page
Reverse
NOT
Mnemonic Operation Reverse
6-49
6.2.4 Master Control Instruction
Classification Designations Name
Details
Page
Master
Control
MCS
Master Control Start
6-50
MCSCLR
Master Control Clear
