(2) Upper link installation and
adjustment
 Adjust the upper link ① depending on the
implements.
 Length of the upper link ① can be adjusted by
turning the grip ② .
 Fasten the lock nut ③ .
 Adjusting range : 15.7 ~ 29.5 inch.
▶ Insert the snap-pin ⑤ correctly to prevent the upper link pin ④ from being
detached.
Notice
(3) Adjustment of the lift rod’s
length
 Lift rod (RH) can be adjusted by loosening the
lock-nut ②
and turning the body ① .
②
②②
②
①
①①
①
④⑤
④⑤④⑤
④⑤
③
③③
③
②
②②
②
4
4 4
4 - 10
 After adjusting, tighten the lock-nut
② again.
(4) Adjustment of stabilizer’s length
 The length of the stabilizer can be adjusted by
turning the handle ②
after removing the fixing-pin ① .
 After adjusting, insert the fixing-pin ① again.
▶ Adjust the clearance of lateral
shaking of the implement to be
within 20~40mm (0.79~1.57 in).
Notice
①
①①
①
①
①①
①
②
②②
②
