When engine oil is warm, the
impurities can be drained
Notice
①
①①
① Drain Engine oil
Run engine for a few minutes to warm oil.
Park the tractor on a level surface.
Remove drain plug of oil pan and drain the oil
completely.
5-7. Every 300 hour check
(1) Replacing Engine oil and Filter
Oil filling port
Oil filter
②
②②
② Replace Engine oil filter
Carefully clean around the filter.
Coat clean engine oil on the packing of new filter
and check the packing is
placed well in the groove.
Turn the oil filter counter-clockwise to remove with
filter wrench.
Turn the new filter clockwise until the packing
makes contact with the mounting surface. Tighten
¾ to 1 turn more after packing contact.
③
③③
③ Fill Engine oil
Tighten the drain plugs.
Fill the engine oil as its capacity and check the oil
5
5 5
5 - 14
level is between “MIN” and “MAX”.
Engine oil capacity : 4.2 L (1.11 U.S. gals)
Check any leakage of the engine while running
the engine for several minutes at idle rpm.
Stop the engine. After several minutes later,
check again the oil level is between “MIN” and
“MAX”.
Install the oil gauge.
Packing
Loosen
Tighten
