LS tractor J2030H User Manual

(2) Maintenance Table
HST type
Checking Part Type & Spec.
Capacity &
Dimension
Check Period (Hours)
Daily 50 300 600 1200
1 Fuel tank See page 5-3 25 ℓ (6.60 U.S. gals)
▲
2 Fuel filter Element
●
3 Engine oil See page 5-3 4.2 ℓ (1.10 U.S. gals)
▲ ●
4 Engine oil filter Cartridge
★ ●
5 Engine coolant See page 5-3 3.8 ℓ (1.00 U.S. gals)
▲ ●
6 Radiator screen
▲ ■
7 Air cleaner Dry
▲ ■ ●
8 Battery
▲
9 Fan belt tension
10~12 mm
(0.39~0.47 in)
▲
10 Valve clearance 0.25 mm (0.0098 in)
▲
11
Nozzle injection
pressure
14.7 MPa (2132 psi)
▲
12 Hydraulic filter Cartridge
See page 5-15
★ ●
HST filter
★ ●
13 Transmission oil See page 5-3 20 ℓ (5.28 U.S. gals)
▲ ●
14 Front axle oil See page 5-3 3 ℓ (0.79 U.S. gals)
▲ ●
15
3
-
point linkage
Grease
Proper amount
▲
5
5 5
5 - 2
★ First Replacement ● Replacement ▲ Check, Adjustment and Supply ■ Clean up
15
3
-
point linkage
Grease
Proper amount
▲
16
HST pedal
Neutral state
▲
17 Break pedal play
▲
18
Turn lights,
Lights, Horn
▲
19
Instrument panel &
Indicators
▲
20 Bolts and Nuts
▲
21 Tire air pressure
▲
22 Toe-in 0~8 mm (0~0.31 in)
▲
