(4)
A
djusting Engine V
alv
e
clearance
Contact y
our authorized dealer
to check the
valve
clearance.
Valve
clearance
: 0.25mm (0.0098
in)
If the
gap
is big, the
noise increase and
if the
gap
is small, the
engine
pow
er can be
low
.
0.
2
5
m
m
(
0
.
0
09
8
in
)
(5) Checking
Nozzle injection
pressure
Contact y
our authorized dealer.
Nozzle injection press
ure :
14.7
MPa
(2132
psi)
5
5
5
5
-
20
77
79
