LS tractor J2030H User Manual

MID. PTO gear stage 1
MID. PTO speed / Engine speed 2000 / 2660 rev/min
Revolution
Direction
Clockwise
(view from end of PTO shaft.)
Shaft dimension
(unit : inch)
Ground Clearance 403(15.9 in) (Tire radius:408mm(16.1 in))
Module : DP 16/32
Number of Teeth : 15T
(1.77 in.)
(0.94 in.)
(0.84 in.)
(0.98 in.)
4
4 4
4 - 12
Warning
▶ If you contact the rotating shaft, it may cause a serious injury.
- DO NOT touch shaft which is rotating.
- DO NOT remove the safety cover.
- Avoid loose clothes that can easily be rolled up in the revolving shaft.
(7) PTO safety cover and protection
cap
 Attach the PTO safety cover always.
 When PTO is not used, apply grease and insert
the PTO protection cap.
PTO protection
cap
PTO safety cover
