Chapter 4 RTD Input Module (XBF-RD04A, XBF-RD01A)

4.11 Filtering Function

Based on the filter value (time-constant) which defines the temperature-converted value of the specified

channel, it performs and outputs calculation as below.

)40(

(

used Channelsvalue Filter

used) Channelstemp.x40 input (Presently)value Filtertemp.x filtered Previously

etemperatur Filtered

×+

msms

• Filtering constant setting range = 160 ~ 64000 [ms]

Temperature( ℃

Filtered Temperature

Actual temperature

100 ℃

63.2 ℃

0 ℃

Time (ms)

Filtering

Constant (ms)

4 - 11
