Chapter 1 General
1 - 1
Chapter 1 General
Here describes about analog module and built-in PID function of XGB series.
1.1 Analog Product List
Classification
Name
No. of
channel
Range
Resolution
Characteristic
Voltage/
Current input
XBF-AD04A
4
0 ~ 10V
2.5 ㎷
1.Range selection by external switch and
parameter setting
2. External DC24V used
0 ~ 20 ㎃
4㎃~20㎃
5.0 ㎂
XBF-AD04C
4
1 ~ 5V
0.250㎷
1.Range selection by external switch and
parameter setting
2 Function of. Filter, Average,
Detection disconnection, Alarm,
Retaining Valid conversion value
3. External DC24V used
0 ~ 5V
0.3125㎷
0 ~ 10V
0.625㎷
±10V
1.250㎷
4 ~ 20㎃
1.0㎂
0 ~ 20㎃
1.25㎂
XBF-AD08A
8
4~20㎃
0~20㎃
5.0 ㎂
1.Range selection by external switch and
parameter setting
2. Filter function, average function
3. External DC24V used
1~5V
0~5V
1.25 ㎷
0~10V
2.5 ㎷
Voltage output
XBF-DV04A
4
0 ~ 10V
2.5 ㎷
1. External DC24V used
2. Designates output in case of Error and
CPU STOP
3. Interpolation function (Linear, S-type)
XBF-DV04C
4
1 ~ 5V
0.250㎷
0 ~ 5V
0.3125㎷
0 ~ 10V
0.625㎷
±10V
1.250㎷
Current output
XBF-DC04A
4
0 ~ 20㎃
4㎃~20㎃
5.0 ㎂
1. External DC24V used
2. Designates output in case of Error and
CPU STOP
XBF-DC04B
4
0 ~ 1.2㎃
0.3㎂
XBF-DC04C
4
4~20㎃
1.0㎂
1. 1. External DC24V used
2. Designates output in case of Error and
CPU STOP
3. Interpolation Function(Linear, S-type)
4. Detection disconnection
0 ~ 20㎃
1.25㎂
RTD input
XBF-RD04A
4
PT100
JPT100
0.1℃
1. External DC24V used
2. Filter function
XBF-RD01A
1
Thermocouple
Input module
XBF-TC04S
4
K / J / T / R
Note1)
1. External DC24V used
2. Filter function, average function
XBF-TC04B
Note1) for more detail on thermocouple input module resolution, refer to Ch.5.2.6 accuracy/resolution.
