LSIS XBF-AD08A

XGB Analog edition manual
3 - 6
3.5 Characteristic of Input/Output
The range of a voltage output is DC 0 ~ 10V and a current output is DC 4 ~ 20mA / DC 0 ~ 20mA.
Digital input value toward analog voltage output is shown below.
Resolution: 2.5mV (1/4000), Accuracy: within ±0.5%
The range of
digital input
Analog voltage output
under 0V
0V
2.5V
5V
7.5V
10V
over 10V
Unsigned value
(-48 ~ 4047)
under 0
0
1000
2000
3000
4000
over 4000
Signed value
(-2048 ~ 2047)
under -2000
-2000
-1000
0
1000
2000
over 2000
Precise value
(-12 ~ 1011)
under 0
0
250
500
750
1000
over 1000
Percentile value
(-12 ~ 1011)
under 0
0
250
500
750
1000
over 1000
Digital input value toward analog current output is shown below.
Resolution: 5μA (1/4000), Accuracy: within ±0.5%
The range of
digital input
Analog current output
under 4mA
4mA
8mA
12mA
16mA
20mA
over 20mA
under 0mA
0mA
5mA
10mA
15mA
20mA
over 20mA
Unsigned value
(-48 ~ 4047)
under 0
0
1000
2000
3000
4000
over 4000
Signed value
(-2048 ~ 2047)
under -2000
-2000
-1000
0
1000
2000
over 2000
Precise value
(381 ~ 2018, -24 ~ 2023)
under 400
400
800
1200
1600
2000
over 2000
under 0
0
500
1000
1500
2000
over 2000
Percentile value
(-12 ~ 1011)
under 0
0
250
500
750
1000
over 1000
