Chapter 5 Thermocouple Input Module (XBF-TC04S,TC04B)
(2) Command sent from XGB main unit to module (XGB PLC output area, read/write available)
Device
assignment
Type Comment Content R/W
Signal
direction
U0x.29.0 BIT
CH 0 max./min. searching
Enable/Disable
Min./max. search
On: enable
Off: disable
R/W
CPU↔TC
U0x.29.1 BIT
CH 1 max./min. searching
Enable/Disable
R/W
U0x.29.2 BIT
CH 2 max./min. searching
Enable/Disable
R/W
U0x.29.3 BIT
CH 3 max./min. searching
Enable/Disable
R/W
U0x.29.8 BIT
CH 0 cold junction compensation
Enable/Disable
Cold junction
compensation
On: enable
Off: disable
R/W
U0x.29.9 BIT
CH 1 cold junction compensation
Enable/Disable
R/W
U0x.29.A BIT
CH 2 cold junction compensation
Enable/Disable
R/W
U0x.29.B BIT
CH 3 cold junction compensation
Enable/Disable
R/W
※ ‘x’ means slot no. where module is installed.
Ex.) U03.29.02: no.3 slot,
CH 2 max./min. searching Enable/Disable (bit)
