Chapter 7 Analog Input Module (XBF-AD08A)
7.2.2 Performance specifications
Performance specifications are as follows.
Items Performance specification
Number of channel 8 channels
Analog input
range
Type Voltage Current
Range
DC 1 ~ 5V
DC 0 ~ 5V
DC 0 ~ 10V
(Input resistance: 1 MΩ or above)
DC 4 ~ 20mA
DC 0 ~ 20mA
(Input resistance 250 Ω)
Digital output
Type 12 bit binary data
Range
Signed value 0 ~ 4000
Unsigned
value
-2000 ~ 2000
Precise
value
100 ~ 500 (DC 1 ~ 5V)
0 ~ 500 (DC 0 ~ 5V)
0 ~ 1000 (DC 0 ~ 10V)
400 ~ 2000 (DC 4 ~ 20
㎃
)
0 ~ 2000 (DC 0 ~ 20㎃)
Percentile
value
0 ~ 1000
Max. resolution
1/4000
1.25㎷ (DC 1~5V, 0~5V)
2.5
㎷
(DC 0~10V)
5㎂ (DC4~20㎃, 0~20㎃)
Accuracy ±0.5% or less
Max. conversion speed 1.5ms/channel
Absolute max. output DC ±15V
DC ±25㎃
Additional
function
Filter function Digital filter (4 ~ 64,000ms)
Average function
Time average (4 ~ 16,000ms)
Count average (2 ~ 64,000 times)
Moving average (2 ~ 100)
Alarm function Detecting disconnection (DC 1~5V, DC4~20mA)
Insulation method
Photo-coupler insulation between I/O terminal and PLC power
(No insulation between channels)
Input terminal 11 point terminal block
I/O points occupied
Fixed type: 64 points
Max. no. of installation
7 (when using XBM(C)-DxxxS type)
10 (when using XB(E)C-DxxxH type)
Consumption
current
Inner (DC 5V)
105mA
External (DC 24V)
85mA
Weight
81g
Module supply power source 20.4~28.8 V
Note1) In order to use analog input module (XBF-AD08A), the following version is needed.
Main unit Version information
XBM-DxxxS type
V2.6
XBC-DxxxH type
V1.9
XEC-DxxxH type
V1.3
XBC-DxxxS type
V1.0
7 - 3
