1.2.10 Thermocouple Input Option Module
Items
XBO-TC02A
Number of input channel
2 channels
Type of input sensor
Thermocouple K / J type (JIS C1602-1995)
Range of input
temperature
K type sensor
-200.0℃ ~ 1300.0℃
J type sensor
-200.0℃ ~ 1200.0℃
Digital output
Temp. display unit
16 bit binary data
Displaying down to one decimal place
(K, J, type: 0.1℃)
Accuracy
±1.0% or less
Conversion speed
50ms/2chanelles –note1)
Reference
junction
compensation
Auto compensation by RJC sensing (Thermistor)
Compensation amount
±1.0℃
Additional
function
Average process
Count averaging
Alarm
Input disconnection detection
Warming-up time
15 min or above – note2)
Insulation method
Non-insulation between input channels
Non-insulation between input terminal and PLC
main unit
I/O terminal
5-point terminal block
Max. number of equipment
1 (when using XBC-DR10E/DR14E type)
2 (when using XBC-DR20E/DR30E type)
2 (when using XBC-DxxxS type)
Supply power
Internal DC5V
I/O occupied points
Fixed type: 64 points
Consumption current
50㎃
Weight
20g
