Chapter 11 RTD Input Option Board (XBO-RD01A)
11.9.3 If 4-wired sensor is used (connection terminal unit is used)
1* If sensor and compensating wire are
shielded, shield line can be connected to FG
terminal of the module.
B
FG
b
A
*1
Terminal block
NC
NC
