Lucent Technologies Round Cell Batteries
Issue 3 December 1999 Installation and Maintenance Records 9 - 3
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
CELL NO. SERIAL NO.
NOTE 1: NOTE 2:
NOTE 3: NOTE 5: NOTE 7:
NOTE 6:
NOTE 4:
SYMBOLS FOR "CRYSTALS" COLUMN.
THE LETTERS "N" (FOR NO) AND "Y"
(FOR YES) SHOULD BE USED FOR
RECORDING THE ABSENCE OR PRESENCE
OF CRYSTALS.
THIS COLUMN IS USED ONLY WHEN
KS20472 CYLINDRICAL CELLS ARE
INVOLVED.
SELECT A PILOT CELL WHEN USING
THE MEASURED END METHOD AND A
TEMPERATURE REFERENCE CELL WHEN
USING THE ARBITRARY LENGTH METHOD.
"AMPS OR AVERAGE CELL VOLTAGE" COLUMN
DURING CHARGE, RECORD AMPS WHEN USING
THE MEASURED END METHOD AND AVERAGE CELL
VOLTAGE WHEN USING THE ARBITRARY LENGTH
METHOD.
WHEN THE ARBITRARY LENGTH METHOD IS
USED, RECORD BOTH AMPS AND BATTERY
VOLTAGE AT THE END OF CHARGE.
WITH 1/4 INCHES AS THE UNIT OF MEASUREMENT
WITH PINTS AS THE UNIT OF MEASUREMENT
4 - 3/4 INCHES OF WATER ADDED
1 - 3/4 INCHES OF ELECTROLYTE REMOVED
27 PINTS OF WATER ADDED
7 PINTS OF ELECTROLYTE REMOVED.
FIRST SYMBOL - ALL CELLS
SECOND AND THIRD SYMBOL FOR HARD RUBBER CELLS
SECOND AND THIRD SYMBOL FOR PLASTIC CELLS
WATER ADDED
ELECTROLYTE REMOVED
ELECTROLYTE ADDED
SECOND AND THIRD SYMBOL INDICATES PINTS
IF LESS THAN 10 PINTS, SHOW A ZERO
(0) AS SECOND SYMBOL.
SECOND AND THIRD SYMBOL INDICATES NUMBER OF
QUARTERS OF AN INCH. IF LESS THAN
10 QUARTERS (2 - 1/2 INCHES), SHOW A
ZERO (0) AS SECOND SYMBOL.
"INDIVIDUAL MEASUREMENTS -
TEMPERATURE"
RECORD THE TEMPERATURE OF AT LEAST
ONE CELL PER TIER. ALL CELL
TEMPERATURES NEED NOT BE RECORDED.
"AVERAGE" CELL VOLTAGE IS
DETERMINED BY DIVIDING THE
BATTERY VOLTAGE BY THE NUMBER
OF CELLS IN THE STRING.
SYMBOL SYMBOL
11
tW
W1 9
W2 7
R
R0 7
R0 7
A
M
M MINIMUM LEVEL
INDICATES LEVEL ANYWHERE BETWEEN 1/2 INCH OF
PLATE EXPOSURE AND MINIMUM LEVEL.
OMIT SECOND SYMBOL.
NUMERICAL SUFFIX WHEN USED WITH PREFIX "M"
INDICATES HEIGHT IN QUARTERS OF AN
INCH ABOVE MINIMUM LEVEL REFERENCE.
(INDICATE TO NEAREST QUARTER OF AN INCH)
PREFIX "M" INDICATES MINIMUM LEVEL REFERENCE
OR
1 - 3/4 INCHES ABOVE MINIMUM LEVEL
0
M7
3
31
03
EXAMPLES EXAMPLES
223
SYMBOLS FOR "AS RECEIVED" COLUMN SYMBOLS FOR "CORRECTED" COLUMN
IN THE APPROPRIATE BOX, INDICATE WITH AND "X" THE UNIT OF
MEASUREMENT USED.
PAGE2OF2
STORAGE BATTERY REPORT
