Lucent Technologies Round Cell Batteries
2 - 4 Product Description Issue 3 December 1999
Battery Stands, continued
Figure 2-1: Dimensions of Battery Stands Equipped
with KS-20472 Round Cells
2'-6"
LIST 1S
Round Cell Battery Stand
for KS-20472, L-1S Batteries
Round Cell Battery Stand
for KS-20472, L-3S Batteries
Round Cell Battery Stand
for KS-20472, L-2S Batteries
Round Cell Battery Stand
for KS-20472, L-4S Batteries
LIST 2S
LIST 3S
LIST 4S
5'
2'-8"
CRAFTSMAN WILL
PROBABLY USE A
LADDER ABOVE
THIS LEVEL
2'-4 3/4"
9'-4"
8'-6 1/2"
9'-8 1/2"
7'-4 3/8"
2'-1/8"
1'-8 7/8"
1'-5 3/8"
1'-8 5/8"
1'-8 5/8"4"
4"
4"
1'-3 5/8"
2'-6"
2'-6" 2'-6"
Top View
2'-6"
1'-3"
