Lucent Technologies KS-20472 - Battery Stands and Ordering

Lucent Technologies Round Cell Batteries
3 - 2 Ordering Information Issue 3 December 1999
Battery Stands
Ordering Table Table 3-B lists the various codes associated with the Round Cell Battery
Stand.
The KS- numbers refer to the Lucent Technologies documents that
specify the design and manufacture of the battery stand equipment. The
P- numbers refer to piece parts required for installation.
Table 3-B: Round Cell Battery Stand Ordering Information
Comcode KS or P No. List No. Description
400771309 KS-20760 1
Back panel for KS-20472, L-1S
Round Cell Battery
400771317 KS-20760 2
Back panel for KS-20472, L-2S
Round Cell Battery
401512009 KS-20760 7
Back panel for KS-20472, L-3S
and L-4S Round Cell Batteries
400773867 KS-20760 5 Base for all Round Cell Batteries
400770558 KS-20760 6 Dovetail key for interlocking bases
401864574 KS-21724 4 Cable guard
401856067 KS-21723 1 Cable bracket
841657166 -- -- Auxiliary framing support
841064793 -- -- Hex nut (2 required with aux framing support)
814947073 P-49D707 -- Bolt (2 required with aux framing support)
801829672 P-182967 --
Lockwasher (2 required with aux framing
support)
814251914 P-42E191 -- Washer (2 required with aux framing support)
Notes:
Use this table for individual units. Refer to Tables 3-C through 3-F for battery stand
arrangements ordering information.
The basic battery stand module consists of the following:
(2) KS-20760, L-5 Base
(2) KS-20760, L-1, L-2, or L-7 Back Panel
(4) KS-20760, L-6 Dovetail Keys for every four Round Cell Batteries
See ED-82563-10 for battery stand arrangements of the KS-20760 Battery Stand soft
sites, earthquake area sites, and hardened sites.
See ED-82868-30 for battery stand arrangement of the KS-20760 Battery Stand for UPS
applications.
