Lucent Technologies KS-20472 - Earthquake Bracing

Lucent Technologies Round Cell Batteries
3 - 6 Ordering Information Issue 3 December 1999
Battery Stands, continued
10 P.S.I.
Earthquake
Bracing
Table 3-F: List of J-Code Drawings for 10 P.S.I. Earthquake
Bracing Battery Stand Arrangements
J-Code Volts
Quantity
Includes Space for
Earthquake
Bracing and
10 P.S.I. Bracing
Material
Per Stand
KS-20472
Lists
Type of
Plant
Tiers Rows Length Width Cells Strings
J85504A
24V 2 2 7'10-1/2" 2'10-1/2" 24 2 L-1S Lineage
48V 2 2 7'10-1/2" 2'10-1/2" 24 1 L-1S Lineage
J87127A 24V 2 2 4'1-1/2" 2'10-1/2" 12 1 L-1S 100
J87127B 24V 2 2 7'10-1/2" 2'10-1/2" 24 2 L-1S 100, 326
J87128A 48V 2 2 7'10-1/2" 2'10-1/2" 24 1 L-1S 100
J87128B 48V 2 2 15'4-1/2" 2'10-1/2" 48 2 L-1S 326
J87128C 48V 2 1 15'4-1/2" 2'10-1/2" 24 1 L-1S 151A
J87130A 140V 2 2 11'10-1/2"2'10-1/2" 70 1
L-1S
L-2S
413A,
415A
Notes:
For hardened 50 P.S.I. sites, use J87131A, and J87131B drawings for battery stand,
bracing material, and shock isolation platform.
For other voltages, use J85504A, J87131A, and J87131B as guides to assemble the
battery stand with bracing material and shock isolation platform.
