Lucent Technologies KS-20472 - 48-volt Battery Plants

Lucent Technologies Round Cell Batteries
3 - 4 Ordering Information Issue 3 December 1999
Battery Stands, continued
48-volt Battery
Plants
Table 3-D: Lists of J-Code Drawings for Battery Stand
Arrangements of 48-volt Power Battery Plants
J-Code Volts
Quantity
Length Width
Per Stand
KS-20472
Lists
Type of
Plant
Tiers Rows Cells Strings
J85504A1 48V 2 1 7'6" 2'6" 24 2 L-1S Lineage
J87124A 48V 2 1 15'0" 1'3" 24 1
L-1S
L-2S
L-3S
L-4S
J87124B 48V 2 2 7'6" 2'6" 24 1
L-1S
L-2S
100, 300
J87124C 48V 2 2 17'10" 2'6" 27 1
L-1S
L-2S
302
J87124D 48V 2 2 15'0" 2'6" 48 2 L-1S 100, 300
J87124E 48V 2 1 15'0" 1'3" 24 1 L-1S 151A
J87124F 48V
2
2
2
2
8'9"
7'6"
2'6"
2'6"
24
24
1
1
L-1S or
L-2S
CEMF
cell
100 and
300
J87124G 48V 3 2 5'0" 2'6" 24 1
L-1S
L-2S
L-3S
L-4S
100
J87124H 48V 4 2 3'9" 2'6" 24 1
L-3S
L-4S
100
J87124J 48V 3 2 5'0" 2'6" 24 1
L-3S or
L-4S
CEMF
cell
100
J87124L 48V 3 1 10'0" 1'3" 24 1
L-2S,
133A
133B
J87124M 48V 2 2 2'6" 2'6" 4 1
L-1S
(EMC)
302S
