Lucent Technologies KS-20472 - 130;140-volt Battery Plants

Lucent Technologies Round Cell Batteries
Issue 3 December 1999 Ordering Information 3 - 5
Battery Stands, continued
130/140-volt
Battery Plants
Table 3-E: Lists of J-Code Drawings for Battery Stand
Arrangements of 130/140-volt Power Battery Plants
J-Code Volts
Quantity
Length Width
Per Stand
KS-20472
Lists
Type of
Plant
Tiers Rows Cells Strings
J87125A 140V 2 2 22'6" 2'6" 70 1 L-1S 415
J87125B 140V 3 2 15'0" 2'6" 70 1 L-1S 415
J87125C 140V 2 2 22'6" 2'6" 70 1 L-2S 415
J87126A 130V 2 2 22'6" 2'6" 69 1
L-1S
L-2S
708A
J87126B 130V 3 2 13'9" 2'6" 63 1 L-3S 411
J87126C 130V 2 2 22'6" 2'6" 66 1
L-1S
L-2S
CEMF
units
412
J87126D 130V 3 2 15'0" 2'6" 66 1
L-1S
L-2S
L-3S
L-4S
CEMF
units
412
J87126E 130V 4 2 11'3" 2'6" 66 1
L-3S
L-4S
CEMF
units
412
J87126F 130V 2 2 22'6" 2'6" 69 1
L-1S
L-2S
702C
708C
J87126G 130V 3 2 15'0" 2'6" 69 1
L-1S
L-2S
L-3S
L-4S
702C,
708A
J87126H 130V 4 2 11'3" 2'6" 69 1
L-3S
L-4S
702C
Note: Use J85504A, ED-82868-30, and ED-82563-10 as guides to order self-configured
battery stands.
