Lucent Technologies KS-20472 - 24-volt Battery Plants

Lucent Technologies Round Cell Batteries
Issue 3 December 1999 Ordering Information 3 - 3
Battery Stands, continued
24-volt Battery
Plants
Table 3-C: Lists of J-Code Drawings for Battery Stand
Arrangements of 24-volt Power Battery Plants
J-Code Volts
Quantity
Length Width
Per Stand
KS-20472
Lists
Type of
Plant
Tiers Rows Cells Strings
J85504A1 24V 2 1 7'6" 2'6" 24 2 L-1S Lineage
J87123A 24V 2 1 7'6" 1'3" 12 1
L-1S
L-2S
L-3S
L-4S
111A
J87123B 24V 2 2 3'9" 2'6" 12 1
L-1S
L-2S
111A
326
J87123C 24V 2 2 8'11-3/4" 2'6" 13 1 L-1S 302
J87123D 24V 2 2 2'6" 2'6" 8 4
L-1S
(EMC)
302B
J87123E 24V 2 2 7'6" 2'6" 12 2 L-1S
111A
151
152
154
326
J87123F 24V 3 2 2'6" 2'6" 12 1
L-2S
L-3S
L-4S
111A
132A
133B
J87123G 24V 3 1 5'0" 1'3" 12 1 L-2S
132A
133B
