Lucent Technologies Round Cell Batteries
8 - 8 Discharge and Power Data Issue 3 December 1999
Table 8-I: Estimated 1 and 5 Minute Rate in Amperes
to 1.75 Volts Per Cell
Model 1 Minute/5 Minute
List 1S 1200
List 2S 800
List 3S 500
List 4S 350
Notes:
The values in this table include intercell connector loss. This loss is
based on the use of two 12" x 2-1/2" x 3/8" lead-plated copper straps
with an average intercell resistance of 19 microohms.
For any given model, the one and five minute rates are the same
because of restrictions imposed by the coup-de-fouet in the discharge
curve.
