Lucent Technologies PortMaster PM-2 User Manual

PortMaster Communications Server 1-3
PortMaster Communications Server Product Line
Figure 1-1 shows the front panel of the PortMaster Communications Server. The
product name displayed on the figure applies to the PM-2 model; the model number
varies for each unit.
Figure 1-1 PortMaster Communications Server Front Panel
Table 1-3 shows the available ports on each PortMaster Communications Server model.
Table 1-4 on page 1-4 shows how to upgrade your PortMaster Communication Server.
Physical specifications are listed in Appendix B.
MOD-10I-ST Offers 5 BRI ports (10 B channels). This board provides
an S/T interface for countries that follow international
ISDN standards.
Ta b l e 1 - 3 Available Port Types by PortMaster Model
Model
Ports
Ethernet Asynchronous Synchronous Parallel BRI U BRI S/T
PM-2 Ether0 S0–S9 P0
PM-2E-10 Ether0 S0–S9 P0
PM-2E-20 Ether0 S0–S19
1
P0 S10–S19
1
S10–S19
1
PM-2E-30 Ether0 S0–S29
1
P0 S10–S29
1
S10–S29
1
PM-2ER-10 Ether0 S0–S9 W1
Ta b l e 1 - 2 Expansion Boards (Continued)
Expansion Board Description
PortMaster 2
Communications Server
1187-0034
