Installing Optional Equipment 3-5
Adding Memory
9. Using a Phillips screwdriver, replace the screw in the top center of the
PortMaster.
10. Connect the PortMaster to the power source and turn the power switch on.
ETHERNET
ISDN/U ISDN/U ISDN/U ISDN/U ISDN/U ISDN/U
S0-S1 S2-S3 S4-S5 S6-S7 S8-S9 HD
C0 - DIAG
1187-0013
