12 TECHNICAL DATA
Measurement ranges and permissible errors
Table 22
Measured quantity
Measurement range
L1
L2
L3
∑
Class
Current I: 1/5 A 1 A~
5 A~
0.002 ..0.100..1.200 A
0.010 ..0.500.. 6.000 A
...100.00 kA (Ki ≠ 1)
•
•
•
0.2 (EN 61557-12)
Voltage U L-N: 57.7 V~
5.700..11.500 ..70.000 V
110 V~
230 V~
400 V~
11.000..22.000 ..132.00 V
23.000..46.000 .. 276.00 V
40.000..80.000 .. 480.00 V
...1920.0 kV
•
•
•
0.2 (EN 61557-12)
Voltage U L-L: 100 V~
10.000 ..20.000..120.00 V
190 V~
400 V~
690 V~
19.000 ..38.000..228.00 V
40.000..80.00 .. 480.00 V
69.000..138.00 .. 830.00 V
...1999.0 kV (tr_U≠1)
•
•
•
0.5 (EN 61557-12)
Active power P
-19999 MW .. 0.000 W ..
..19999 MW (tr_U≠1,tr_I≠1)
•
•
•
•
0.5 (EN 61557-12)
Reactive power Q
-19999 MVar .. 0.000 Var ..
..19999 MVar (tr_U≠1,tr_I≠1)
•
•
•
•
1 (EN 61557-12)
Apparent power S
0.000 .. 1999.9 VA ..
..19999 MVA (tr_U≠1,tr_I≠1)
•
•
•
•
0.5 (EN 61557-12)
Active energy EnP
/ imported or exported /
0.000 .. 99 999 999, 999 kWh
•
0.5
1)
(EN 61557-12)
Reactive energy EnQ
/Inductive or capacitive/
0.000 .. 99 999 999, 999 kVarh
•
1 (EN 61557-12)
Apparent energy EnS
0.000 .. 99 999 999, 999 kVAh
•
0.5 (EN 61557-12)
Active power factor
PF
-1.00 .. 0 .. 1.00
•
•
•
•
1 (EN 61557-12)
Coefficient tgφ
-1.20 .. 0 .. 1.20
•
•
•
•
1
Frequency f
45.000 ..65.000 Hz
•
0.1 (EN 61557-12)
Total harmonic
distortion of voltage
THDU, and current
THDI
0.0 .. 100.0 %
•
•
•
•
5 (EN 61557-12)
Amplitudes of of the
voltage U
h2
...U
h51
,
and current I
h2
… I
h51
0.0 .. 100.0 %
•
•
•
II (IEC61000-4-7)
tr_I - Ratio of current transformer = Primary current of transformer / Secondary current of current transformer,
tr_U - Ratio of voltage transformer = Primary voltage of transformer / Secondary voltage of voltage transformer,
1)
Class 0.5 S acc. to EN 62053-22
