ND30PNET-09 - User's Manual
37
9 MAP OF REGISTERS OF ND30PNET METER
In ND30PNET meter the data is placed in 16- and 32-bit registers. Process variables and
parameters of the meter are located in the address space of registers in a manner dependent on
the type of the variable. Bits in 16-bit registers are numbered from the youngest to the oldest
(b0-b15). 32-bit registers contain floating point numbers in IEEE-754 standard. Bytes sequence
3210 – the oldest is sent first.
Table 15
Address range
Value
type
Description
4000 – 4159
Integer
(16 bits)
Value placed in one 16-bit register. Registers for meter configuration.
Description of registers can be found in table 16. Registers for recording and
reading.
4200 – 4260
Integer
(16 bits)
Value placed in one 16-bit register. Registers for configuration of
programmable read-only register group Registers description can be found
in table 15 Registers for recording and reading.
4300 - 4385
Integer
(16 bits)
Value placed in one 16-bit register. Registers for configuration of displayed
pages, Description of registers can be found in table 19. Registers for
recording and reading.
4400- 4446
Integer
(16 bits)
Value placed in single 16-bit register. Registers of statuses, energy values,
the meter MAC address, configuration data. Description of registers can be
found in table 20. Read-only registers.
4500- 4620
Integer
(16 bits)
Value placed in single 16-bit register. Name of Profinet device. Description
of registers can be found in table 21. Registers for recording and reading.
6000 – 6922
Float
(2x16 bits)
Value placed in two successive 16-bit registers. Registers contain the same
data as 32-bit registers of 7500 – 7953 range. Read-only registers. Byres
order (1-0-3-2)
7000 - 7118
Float
(2x16 bits)
Content of registers set in registers 4200 – 4359. Bytes order (3-2-1-0)
7200 – 7318
Float
(2x16 bits)
Content of registers set in registers 4200 – 4359. Bytes order (1-0-3-2)
7400 - 7459
Float
(32 bits)
Content of registers set in registers 4200 – 4359. Values placed in single
32-bit register.
7500 – 7961
Float
(32 bits)
Values placed in single 32-bit register. Description of registers can be found
in table 22. Read-only registers.
8000 - 8922
Float
(2x16 bits)
Value placed in two successive 16-bit registers. Registers contain the same
data as 32-bit registers of 7500 – 7953 range. Read-only registers. Byres
order (3-2-1-0)
