ND30PNET-09 - User's Manual
38
Table 16
Connections layout
0 - 3Ph/4W
1 - 3Ph/3W
2 - 1Ph/2W
Voltage at terminal 2:
0 - voltage of the first phase L1
1 - voltage of the second phase L2
2 - voltage of the third phase L3
Voltage at terminal 5:
0 - voltage of the first phase L1
1 - voltage of the second phase L2
2 - voltage of the third phase L3
Voltage at terminal 8:
0 - voltage of the first phase L1
1 - voltage of the second phase L2
2 - voltage of the third phase L3
Current at terminals 1,3:
0 - current of the first phase I
L1
1 - reversed current direction of phase L1: -I
L1
2 - current of the second phase I
L2
3 - reversed current direction of phase L2: -I
L2
4 - current of the third phase I
L3
5 - reversed current direction of phase L3: -I
L3
Current at terminals 4,6:
0 - current of the first phase I
L1
1 - reversed current direction of phase L1: -I
L1
2 - current of the second phase I
L2
3 - reversed current direction of phase L2: -I
L2
4 - current of the third phase I
L3
5 - reversed current direction of phase L3: -I
L3
Current at terminals 7,9:
0 - current of the first phase I
L1
1 - reversed current direction of phase L1: -I
L1
2 - current of the second phase I
L2
3 - reversed current direction of phase L2: -I
L2
4 - current of the third phase I
L3
5 - reversed current direction of phase L3: -I
L3
Current input range: 1A or 5 A: 0 - 1 A, 1 - 5 A
Voltage input range:
0 – 3 x 57,7/100 V; 1 – 3 x 230/400 V (version 1)
0 – 3 x 110/190 V; 1 – 3 x 400/690 V (version 2)
Primary voltage of transformer, two younger bytes
Secondary voltage of transformer x 10
Primary current of transformer
Secondary current of transformer
Averaging time of active power P Demand, apparent
power S Demand,
current I Demand
0 – 15, 1- 30, 2- 60 minutes
