ND30PNET-09 - User's Manual
39
Synchronization with real time clock
0 - no synchronization
1 - synchronization with the clock
Leads resistance value for input T1 x 100
Leads resistance value for input T2 x 100
Resetting energy meters:
0 – no changes, 1- reset active energies,
2 – reset reactive energies, 3 – reset apparent energies, 4 –
reset all energies
Resetting averaged parameters P
Demand, S Demand, I
Demand
Resetting alarm signaling maintenance
Alarm output 1- logic actions of conditions 1, 2, 3
0 – C1
1 – C1 v C2 v C3
2 – C1 C2 C3
3 – C1 C2 v C3
4 – (C1 v C2 C3
Alarm output 1- state of relay at alarm occurrence: 0 - relay off
1 - relay on
Alarm output 1- lock of alarm deactivation
Alarm output 1- signaling of alarm occurrence
Alarm output 1 - quantity for condition 1 (c1)
(code acc. to table 8)
Alarm output 1 – type for condition 1: 0 – n_on, 1 – noFF, 2
– on, 3 – oFF, 4 – H_on, 5 – HoFF, 6 – 3non, 7 – 3noF,
8 – 3_on, 9 – 3_oF
Alarm output 1 - lower value of switching condition 1 of
input nominal range
Alarm output 1 - upper value of switching condition 1 of
input nominal range
Alarm output 1 – delay of condition 1 activation
Alarm output 1 – delay of condition 1 deactivation
Alarm output 1 – lock of condition 1 reactivation
Alarm output 1 – signaling condition 1 occurrence
Alarm output 1 - quantity for condition 2 (c2) (code acc. to table 8)
Alarm output 1 – type for condition 2: 0 – n_on, 1 – noFF, 2
– on, 3 – oFF, 4 – H_on, 5 – HoFF, 6 – 3non, 7 – 3noF,
8 – 3_on, 9 – 3_oF
Alarm output 1 - lower value of switching condition 2 of
input nominal range
