Tsp
Set point on
the segment
end
0.0 °C MIN…MAX
1)
time
Segment
duration
00.01 00.01…99.59
2)
rr
Accretion
rate of the set
point
0.1
0.1..
550.0 °C /
time unit
4)
(0.1...990.0
°F / time
unit
4)
1..5500 °C
3)
/
time unit
4)
(1...9900
°F
3
)/
time unit
4)
Hldu
Value of the
control devia-
tion for which
the counting
of set point is
interrupted
0.0 0,0...
200.0 °C
(0,0...
360.0 °F)
0...2000
°C
3)
(0...3600°F
3)
)
eu1
State of the
auxiliary
output no 1
off
off: disabled
on: enabled
eu2
State of the
auxiliary
Output no 2
off
off: disabled
on: enabled
pid
PID set for
the segment
pid1
pid1: PID1
pid2: PID2
pid3: PID3
pid4: PID4
1) See table 2.
2) The time unit is defi ned by the parameter tMun
3) The resolution to show the given parameter depends on the parameter
dp – Position of the decimal point.
4) The time unit is defi ned by the parameter rRun
Parameter
symbol
Parameter
description
Manufac-
-turer’s
setting
Range of parameter
change
sensors linear input
type
Kind of seg-
ment
time
time: segment defi ned
by the time
rate: segment defi ned
by the accretion
duel: set point withstand
end: program end
