Colibri Manual Ver. 4.2 Dec 2006
LX Navigation d.o.o. www.lxnavigation.si
29
7 Problems
The following problems and messages might be seen:
• If INIT MEMORY appears after each power up, the lithium back up battery is defective and should be
exchanged by an authorized LX service dealer.
• Unit ‘hangs’ during initialization. The most likely reason is a corrupted TP/TSK data base. Carry
out the INIT MEMORY procedure (see below) and reload the data base. If it happens again, then the
TP/TSK database may be corrupt - look for strange characters and glitches. If LXe is used to load the
database, it automatically checks for corruption and will not allow it to be loaded if corrupt. However,
third party programs may not provide this protection
• SEAL NOT valid message informs that the electronic data security seal has operated. If this message
is seen in conjunction with the INIT MEMORY message, then the lithium data back up is defective and
should be replaced. If the seal defect alone is reported, then a possible reason is the use of third party
programs. Both these defects can be repaired by an authorized LX service dealer. An unsealed unit
will continue to operate satisfactorily when the ESC button is pressed, but the ‘G’ record will be
missing and any flight records downloaded will fail IGC validation.
• If it is required to delete all flight records stored in the memory, then select ‘99999’ in the Password
option.
7.1 INIT MEMORY procedure
• Remove power from the Colibri
• Press and hold the◄ ► and EVENT/PC buttons
• Power Colibri on
• Release all three buttons
• INIT MEMORY will appear for a few seconds
• After using INIT MEMORY, all flights, TP/Tasks and APT data will be erased and will require to be
reloaded
8 Baro calibration procedure
• Input like pilot name “BARO TEST”(not necessary but recommended)
• Set log time to 1 s
• put the instrument into baro chamber and switch it on ( antenna not necessary)
• climb rapidly to apr. 100m to start recording
• put the baro chamber to 1013,2 HPa and wait one or two minutes to get base line
• start climbing till 1000m and remain on 1000 m for apr. 30 seconds
• repeat described procedure till 6000 m or higher
• descend in 1000 m steps till 1013,2 HPa
• open the chamber and switch the unit off for min 5 minutes
• Connect the instrument to PC and read the last flight
• print out BARO TEST “flight”
• restore log time to default
• if a table is necessary, do it manually using LXe/Barogram
Example:
